Energy-Saving Outdoor Series

一、 What do our customers expect from engergy saving LED display?
Lower Power Consumption
In most customers’ eyes, energy saving means lower power consumption and lower power costs.
Slightly higher price
Slightly higher price for energy-saving LED display means reasonably higher investment on the stage of purchase.
二、Why energy-saving has been termed only as an additional value in the marketing of LED display?
The fact is most clients are uncertain about the long-turn investment return of energy-saving LED displays and the difference between normal and energy-saving LED displays.
三、Energy saving is an integrated solution with the keyword “saving”
3.1 The ways of energy-saving we are familiar with are as follows:
1) Applying LED lamp with high lighting effect and reducing the electric energy waste due to the heating of the LED lamps themselves.
2) Applying high-efficiency power supply and reducing the electric energy waste due to the heating of the power supply itself.
According to the principle of conservation of energy, the total input drive power = total output power+ heating power loss of the power supply. The high efficiency power supply reduces the consumption of power due to heating and enhances the output of total power as to supply to the load modules.
3) Applying energy-saving IC and reducing electric energy waste due to the heating of IC itself.
Energy saving IC means lower pressure drop while the IC is working. As we all know, Power consumption=electric current x pressure drop, with the same electric current, lower pressure drop means lower power consumption. Normally, the energy saving driving IC’s pressure drop is 0.2V, while the regular driving IC is 0.5V.
4)Special electric circuit design, reducing the power loss.

The pressure drops of red, green and blue lamps are respectively 1.8v,3.3v and 3.3v. Added with other components’ pressure drop, the input voltage to red, green and blue lamps are 2.8V, 3.8V, and 3.8V.
Regularly, we use the same input voltage for red, green and blue lamps, for example 5V, which means there will be some pressure drop lost, red lamps(5V-1.8V=3.2V), green lamps(5V-3.3V=2.7V) and blue lamps(5V-3.3V=2.7V).
While, our energy saving product uses 2.8V power for red lamps, 3.8V power for green and blue lamps, thus reducing the pressure drop loss.
5)Automatic brightness control, reducing power consumption during cloudy days and night time.

As we all know, the higher brightness means higher power consumption. During cloudy days and night time, we can reduce the led display brightness automatically with automatic brightness control system, which will further reduce the total power consumption.
3.2 Where else did we do except the above ?
1)Waterproof modules can be exposed to the air directly, thus dissipating the heat and eliminate the air conditioner costs.
2）Use aluminum cabinet, eliminating the wrap-up costs
Aluminum cabinet can be exposed to air directly, and there will be no rustiness and there is no need to wrap up the whole display.
3）All modules are connect to the hub card with same distance, reducing energy loss during transmission.
The hub card is installed in the center of cabinet, all modules are connected to the hub card with same distance, thus reducing the energy loss during signal and power transmission.
4）Fan-Free Design
There is no fans, reducing the energy cost by fans.

四、Features of Energy saving product M-100D
1)      Energy Saving and Eco Friendly
With 7000 nits brightness and 300W maximum power consumption, saving energy 50% or more than regular products.
2)Same Steel Structure Design with Old Displays
960mm x960mm cabinets size and same installation holes, new products can use the old steel structure.
3) Low Investments
Single panel weight 27.5KG, 50% of traditional steel cabinet; Waterproof modules, natural heat dissipation, no need of air conditioner; naked steel structure and installation, no need of wrap-up.
4)Simple and Stable
Signal transmitted by pins instead of flat cables, which can greatly reduce failure rates. After the display in finished installation, you can not see any cables outside, obviously, which will be more stable in fierce environment.
5)Total front service or rear service available
Modules, power supplies and receiving cards can be maintained from front or back.
6)Slim and Market Leading Outlook Design
Cabinet thickness only 95mm, aluminum material makes the cabinet look more elegant and stronger.
五、What is the value of new energy-saving M-100D led display to bring customers?
The first “saving” saving electricity
which means 1 kilowatt-hour per,the power consumption of averagely 100W which means 1.
The second“saving”, saving the initial investmentThe energy-saving design renders slight adjustment to the price, which does not let the clients worry about the investment during purchase;

Half weight and half thickness, saving transportation work and installation work, saving steel framing work for more than half;
Water-proof modules, heat radiating in a natural way, aluminum cabinet – you don’t need to worry about rain and it saves you the cost of air conditioning and decoration cost.
The third “saving”, saving cost of transportation and maintenance

Pin-type signal transmission, no bare wire after installation, enhancement of the stability – these features save the maintenance expenditure.
The fourth “saving”, saving the re-investment of updating old screens

Retaining the cabinet size of 960*960 and the classic installation holes results in saving the re-investment of steel framing of updating old screens.
